Item# 7353

Features:

• Provides overcurrent protection for inverters, bow thrusters, and windlasses
• Combines switching and circuit protection into a single device
• "Trip Free"—cannot be held closed after trip

Specifications:

• Amperage:20A AC
• 20A DC
• Color:White
• Actuator Style: Toggle
• Poles:1
• Maximum Voltage:240V AC
• 80V DC
• Circuit Breaker Type: Magnetic Hydraulic - trip free
• Terminal Stud Torque:35 in-lb (3.95 Nm)
• Interrupt Capacity: 5000A 125V AC
• 5000A 240V AC
• 10000A 80V DC
• Minimum Operating Temperature: -40° C
• Maximum Operating Temperature: 85° C
• Mounting Screw:6-32 Stainless Steel
• Mounting Screw Torque:6 in-lb (0.68 Nm)
• Switching Cycles:10000
• Terminal Stud:1/4-20 Tin-Plated Brass
• Weight:0.25lb (0.11 kg)
